FSU1000A
Automatic Vertical Form, Fill and Seal Low-Acid Aseptic Packaging Machine
Suitable for Low Acid Liquid Food and Beverage with or without Particulates and Pharmaceuticals
The FSU1000A is an automatic VFFS packaging machine designed to produce flat pouches of low acid products all under sterile conditions.
The frame and components in contact with the product are made from 300 series stainless steel for easy cleaning, with filling systems built to sanitary standards.
The FSU1000A is designed to meet the applicable USFDA Code of Federal Regulations (CFR 21 part 113) for thermally processed, low-acid foods and liquids, packaged in hermetically sealed containers. Our North American-based Technical Support Team can provide equipment installation, service and on-site training.
Packaging Applications:
- Food & Beverage
- Nutraceutical
- Pharmaceutical
- Aseptic Fill
Benefits:
- Complete Washdown Construction
- Maintains a Sterile Forming and Filling Enclosure
- SIP (Sterilize in Place) & CIP (Clean in Place) Controls
- Lower Packaging Costs vs. Bags Filled on Bag-in-Box Equipment
- Automatic Film and Machine Sterilization Process
- Meets Strict Hygienic Requirements
- Easily Seals Through Product
Features:
- Stainless Steel Construction
- NEMA 4X Control Panel with PLC Controls
- Touchscreen HMI
- HEPA Air Filtration and Hydrogen Peroxide Distribution
- Filling Systems Built to Sanitary Standards
- VFFS Machine Utilizing Rollstock Material
- Validated by Process Authority to Meet Sterility Requirements
- Vertical Seals Made with Heat Sealing
Filling System Options:
- Mass Flow Meter
- Servo Rotary PD Pump
- Magnetic Metering Filler
- Time/Pressure/Orifice
- Piston Pump
Package Finishing:
- Printed and Unprinted Flat Pouch in Foil or Clear Barrier Film
Options:
- Fitment Applicator
- Horizontal Seals Made with Ultrasonic Sealing
- Tear Notch
- Date Coding
- Multi-Lane Pouch Forming
- Inkjet/Thermal Transfer Product Coding
- Discharge Conveying
- Fully Integrated Downstream Equipment
- Unwinder with Automatic Roll Splicing
- Aseptic Product Surge Tank
- Registered Print
- Inert Gas Flush to Reduce Oxygen in the Package
Production Speed:
- Up to 30-35 Cycles per Minute (production speed varies with pouch size and product characteristics)
Package Capacity:
- 10 milliliters to 10 liters (10ml is multi-lane size)
Package Size:
- Min. 35mm x 135mm (1.4in x 5.3in)
- Max. 356mm x 559mm (14in x 22in)
A System Approach to Flexible Packaging
Your customized packaging system with Fres-co's FSU1000A might include:
